Satech Disegna Software: Your Perimeter in 3 easy steps

Disegna Software

Your Perimeter in 3 easy steps

DOWNLOAD THE LATEST RELEASE (2,62 GB)

Disegna 5.0 is the free design software for our customers and distributors that makes it easy to ask for a quote.

The simple and intuitive interface is based on the same software used by our Quotations Department and features the full database of Satech Products (Doors and Locks) as well as Satech Systems (including the new EasyGuard and ImpactGuard).

You can design starting from a blank page or by importing your existing layout in a standard format (DWG, PDF, etc…). You will get the list of the modules for your quotation in just 3 steps.

  • Satech Disegna Software 5.0 - featuring the New Range of Systems
Draw||
1
Draw

your Perimeter by selecting among Systems, Doors, Locks and Custom Panels from the menu.

Visualize||
2
Visualize

your design in perspective by using the 3D View, Zoom and Pan functions.

Save||
3
Save

the list of all the Products used (CSV file) as well as your perimeter layout (DWG file).

Disegna will automatically calculate the Bill of Materials required to ask us a free quotation.

Download Disegna 5.0 for free here

Disegna 5.0 - NEW SYSTEMS

2,62 GB | Includes User Manual (in English) | For Windows
Would you like to proceed with the download of Disegna 5.0 (2,62 GB)?
Confirm

Disegna 5.0 - User Manual

Last update: October 2023 | In English
Download

For information, installation support and general assistance:

disegna@satech.it

Global distribution and offer availability

Satech Solutions are distributed in over 40 Countries worldwide, locally.

Systems composition, product availability and technical specifications might vary depending on your geographic area of interest.

Your local Satech Representative is available to help you choose and to provide you with the latest information.
